Overview
The CODOL CSG Hybrid AC/DC Solar Sewage Pump combines the advantages of solar energy and AC utility power to provide dependable wastewater drainage under all weather conditions. Its intelligent hybrid controller ensures uninterrupted operation, making it ideal for municipal drainage, flood control and industrial wastewater handling.
Features
- Intelligent hybrid AC/DC controller
- Automatic switching between solar and AC power
- Permanent magnet brushless DC motor
- Heavy-duty sewage hydraulic design
- Excellent solids handling capability
- Dry-run and overload protection
- Corrosion-resistant construction
- Long service life
Applications
- Sewage drainage
- Wastewater treatment
- Flood control
- Construction sites
- Municipal drainage
- Industrial wastewater
- Fish ponds and aquaculture
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power(W) | Power(HP) | Max flow (m³/h) | Max head (m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|---|
| CSG15-16-96-750-2AC/DC | 96 | 90~240 | 50~400 | 750 | 0.9975 | 15 | 16 | 1.5"/2" | 2 |
| CSG17-20-110-1100-2AC/DC | 110 | 90~240 | 50~400 | 1100 | 1.463 | 17 | 20 | 1.5"/2" | 2 |
| CSG40-10-144-1100-AC/DC | 144 | 90~240 | 50~400 | 1100 | 1.463 | 40 | 10 | 3" | 2 |
| CSG45-12-192-1500-AC/DC | 192 | 90~240 | 50~400 | 1500 | 1.995 | 45 | 12 | 3" | 2 |
| CSG48-10-192-1500-AC/DC | 192 | 90~240 | 50~400 | 1500 | 1.995 | 48 | 10 | 4" | 2 |
| CSG56-14-280-2200-AC/DC | 280 | 90~240 | 50~400 | 2200 | 3.026 | 56 | 14 | 4" | 2 |
| CSG15-16-96-750-2AC/DCLV | 96 | 90~240 | 50~400 | 750 | 0.9975 | 15 | 16 | 1.5"/2" | 2 |
| CSG17-20-115-1100-2AC/DCLV | 115 | 90~240 | 50~400 | 1100 | 1.463 | 17 | 20 | 1.5"/2" | 2 |
| CSG40-10-115-1100-AC/DCLV | 115 | 90~240 | 50~400 | 1100 | 1.463 | 40 | 10 | 3" | 2 |
| CSG45-12-125-1500-AC/DCLV | 125 | 90~240 | 50~400 | 1500 | 1.995 | 45 | 12 | 3" | 2 |
| CSG48-10-125-1500-AC/DCLV | 125 | 90~240 | 50~400 | 1500 | 1.995 | 48 | 10 | 4" | 2 |
| CSG56-14-205-2200-AC/DCLV | 205 | 90~240 | 50~400 | 2200 | 3.026 | 56 | 14 | 4" | 2 |
