Overview
The CODOL BPCA Integrated Controller Solar Borehole Pump combines the motor and intelligent MPPT controller into one compact unit, eliminating the need for an external controller box. Featuring a plastic impeller, cast iron oil chamber and stainless steel inlet and outlet, it offers reliable performance for clean water pumping in residential, agricultural and off-grid applications.
Features
- Integrated MPPT controller
- Plastic impeller for efficient water delivery
- Cast iron oil chamber
- Stainless steel inlet and outlet
- Direct solar panel connection
- Dry-run protection
- Over-voltage and overload protection
- Easy installation with reduced wiring
Applications
- Borehole water supply
- Agricultural irrigation
- Domestic water systems
- Livestock watering
- Water storage tanks
- Rural water projects
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power (W) | Max flow (m³/h) | Max head(m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|
| 3BPCA3.0/25-24/300 | 24 | ＜55 | 18~45 | 300 | 3.0 | 25.0 | 1" | 2 |
| 3BPCA3.0/45-48/400 | 48 | ＜105 | 40~90 | 400 | 3.0 | 45.0 | 1" | 2 |
| 3BPCA3.5/70-72/600 | 72 | ＜160 | 60~120 | 600 | 3.5 | 70.0 | 1" | 2 |
| 3BPCA3.5/90-96/750 | 96 | ＜210 | 80~150 | 750 | 3.5 | 90.0 | 1" | 2 |
| 3BPCA3.5/120-144/1100 | 144 | ＜450 | 130~400 | 1100 | 3.5 | 120.0 | 1" | 2 |
| 3BPCA3.5/150-192/1500 | 192 | ＜450 | 140~400 | 1500 | 3.5 | 150.0 | 1" | 2 |
| 3BPCA3.5/230-280/2200 | 280 | ＜450 | 180~430 | 2200 | 3.5 | 230.0 | 1" | 2 |
| 3BPCA6.0/40-72/600 | 72 | ＜160 | 60~120 | 600 | 6.0 | 40.0 | 1" | 2 |
| 3BPCA6.5/55-96/750 | 96 | ＜210 | 80~150 | 750 | 6.5 | 55.0 | 1" | 2 |
| 3BPCA6.5/80-144/1100 | 144 | ＜450 | 130~400 | 1100 | 6.5 | 80.0 | 1" | 2 |
| 3BPCA6.5/120-192/1500 | 192 | ＜450 | 140~400 | 1500 | 6.5 | 120.0 | 1" | 2 |
| 3BPCA6.5/160-280/2200 | 280 | ＜450 | 180~430 | 2200 | 6.5 | 160.0 | 1" | 2 |
| 3BPCA3.0/25-24/300-LV | 24 | ＜55 | 18~45 | 300 | 3.0 | 25.0 | 1" | 2 |
| 3BPCA3.0/45-48/400-LV | 48 | ＜105 | 40~90 | 400 | 3.0 | 45.0 | 1" | 2 |
| 3BPCA3.5/70-48/600-LV | 48 | ＜105 | 40~90 | 600 | 3.5 | 70.0 | 1" | 2 |
| 3BPCA3.5/90-48/750-LV | 48 | ＜105 | 40~90 | 750 | 3.5 | 90.0 | 1" | 2 |
| 3BPCA3.5/120-110/1100-LV | 110 | ＜210 | 90~160 | 1100 | 3.5 | 120.0 | 1" | 2 |
| 3BPCA3.5/150-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 3.5 | 150.0 | 1" | 2 |
| 3BPCA3.5/150-125/1500 | 125 | ＜450 | 110~400 | 1500 | 3.5 | 150.0 | 1" | 2 |
| 3BPCA3.5/230-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 3.5 | 230.0 | 1" | 2 |
| 3BPCA3.5/230-205/2200 | 205 | ＜450 | 160~420 | 2200 | 3.5 | 230.0 | 1" | 2 |
| 3BPCA6.0/40-48/600-LV | 48 | ＜105 | 40~90 | 600 | 6.0 | 40.0 | 1" | 2 |
| 3BPCA6.5/55-48/750-LV | 48 | ＜105 | 40~90 | 750 | 6.5 | 55.0 | 1" | 2 |
| 3BPCA6.5/80-110/1100-LV | 110 | ＜210 | 90~160 | 1100 | 6.5 | 80.0 | 1" | 2 |
| 3BPCA6.5/120-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 6.5 | 120.0 | 1" | 2 |
| 3BPCA6.5/120-125/1500 | 125 | ＜450 | 110~400 | 1500 | 6.5 | 120.0 | 1" | 2 |
| 3BPCA6.5/160-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 6.5 | 160.0 | 1" | 2 |
| 3BPCA6.5/160-205/2200 | 205 | ＜450 | 160~420 | 2200 | 6.5 | 160.0 | 1" | 2 |
| 4BPCA3.0/30-24/300 | 24 | ＜55 | 18~45 | 300 | 3.0 | 30.0 | 1.25" | 2 |
| 4BPCA3.5/70-72/600 | 48 | ＜105 | 40~90 | 400 | 3.5 | 50.0 | 1.25" | 2 |
| 4BPCA3.5/50-48/400 | 72 | ＜160 | 60~120 | 600 | 3.5 | 70.0 | 1.25" | 2 |
| 4BPCA3.5/90-96/750 | 96 | ＜210 | 80~150 | 750 | 3.5 | 90.0 | 1.25" | 2 |
| 4BPCA3.5/120-144/1100 | 144 | ＜450 | 130~400 | 1100 | 3.5 | 120.0 | 1.25" | 2 |
| 4BPCA4.5/130-192/1500 | 192 | ＜450 | 140~400 | 1500 | 4.5 | 130.0 | 1.25" | 2 |
| 4BPCA4.5/190-280/2200 | 280 | ＜450 | 180~430 | 2200 | 4.5 | 190.0 | 1.25" | 2 |
| 4BPCA6.0/30-48/400 | 48 | ＜105 | 40~90 | 400 | 6.0 | 30.0 | 1.5" | 2 |
| 4BPCA6.0/40-72/600 | 72 | ＜160 | 60~120 | 600 | 6.0 | 40.0 | 1.5" | 2 |
| 4BPCA6.5/55-96/750 | 96 | ＜210 | 80~150 | 750 | 6.5 | 55.0 | 1.5" | 2 |
| 4BPCA6.5/85-144/1100 | 144 | ＜450 | 130~400 | 1100 | 6.5 | 85.0 | 1.5" | 2 |
| 4BPCA7.0/110-192/1500 | 192 | ＜450 | 140~400 | 1500 | 7.0 | 110.0 | 1.5" | 2 |
| 4BPCA7.5/150-280/2200 | 280 | ＜450 | 180~430 | 2200 | 7.5 | 150.0 | 1.5" | 2 |
| 4BPCA9.0/30-72/600 | 72 | ＜160 | 60~120 | 600 | 9.0 | 30.0 | 2" | 2 |
| 4BPCA9.0/45-96/750 | 96 | ＜210 | 80~150 | 750 | 9.0 | 45.0 | 2" | 2 |
| 4BPCA9.0/65-144/1100 | 144 | ＜450 | 130~400 | 1100 | 9.0 | 65.0 | 2" | 2 |
| 4BPCA10.0/95-192/1500 | 192 | ＜450 | 140~400 | 1500 | 10.0 | 95.0 | 2" | 2 |
| 4BPCA10.0/130-280/2200 | 280 | ＜450 | 180~430 | 2200 | 10.0 | 130.0 | 2" | 2 |
| 4BPCA13.0/30-96/750 | 96 | ＜210 | 80~150 | 750 | 13.0 | 30.0 | 2" | 2 |
| 4BPCA14.0/45-144/1100 | 144 | ＜450 | 130~400 | 1100 | 14.0 | 45.0 | 2" | 2 |
| 4BPCA14.5/70-192/1500 | 192 | ＜450 | 140~400 | 1500 | 14.5 | 70.0 | 2" | 2 |
| 4BPCA14.5/100-280/2200 | 280 | ＜450 | 180~430 | 2200 | 14.5 | 100.0 | 2" | 2 |
| 4BPCA20.0-45-192/1500 | 192 | ＜450 | 140~400 | 1500 | 20.0 | 45.0 | 2" | 2 |
| 4BPCA20.0-65-280/2200 | 280 | ＜450 | 180~430 | 2200 | 20.0 | 65.0 | 2" | 2 |
| 4BPCA30.0-35-280/2200 | 280 | ＜450 | 180~430 | 2200 | 30.0 | 35.0 | 2" | 2 |
| 4BPCA3.0/30-24/300-LV | 24 | ＜55 | 18~45 | 300 | 3.0 | 30.0 | 1.25" | 2 |
| 4BPCA3.5/50-48/400-LV | 48 | ＜105 | 40~90 | 400 | 3.5 | 50.0 | 1.25" | 2 |
| 4BPCA3.5/70-48/600-LV | 48 | ＜105 | 40~90 | 600 | 3.5 | 70.0 | 1.25" | 2 |
| 4BPCA3.5/90-48/750-LV | 48 | ＜105 | 40~90 | 750 | 3.5 | 90.0 | 1.25" | 2 |
| 4BPCA3.5/120-110/1100-LV | 110 | ＜210 | 90~160 | 1100 | 3.5 | 120.0 | 1.25" | 2 |
| 4BPCA4.5/130-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 4.5 | 130.0 | 1.25" | 2 |
| 4BPCA4.5/130-125/1500 | 125 | ＜450 | 110~400 | 1500 | 4.5 | 130.0 | 1.25" | 2 |
| 4BPCA4.5/190-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 4.5 | 190.0 | 1.25" | 2 |
| 4BPCA4.5/190-205/2200 | 205 | ＜450 | 160~420 | 2200 | 4.5 | 190.0 | 1.25" | 2 |
| 4BPCA6.0/30-48/400-LV | 48 | ＜105 | 40~90 | 400 | 6.0 | 30.0 | 1.5" | 2 |
| 4BPCA6.0/40-48/600-LV | 48 | ＜105 | 40~90 | 600 | 6.0 | 40.0 | 1.5" | 2 |
| 4BPCA6.5/55-48/750-LV | 48 | ＜105 | 40~90 | 750 | 6.5 | 55.0 | 1.5" | 2 |
| 4BPCA6.5/85-110/1100-LV | 110 | ＜210 | 90~160 | 1100 | 6.5 | 85.0 | 1.5" | 2 |
| 4BPCA7.0/125-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 7.0 | 125.0 | 1.5" | 2 |
| 4BPCA7.0/125-125/1500 | 125 | ＜450 | 110~400 | 1500 | 7.0 | 125.0 | 1.5" | 2 |
| 4BPCA7.5/160-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 7.5 | 160.0 | 1.5" | 2 |
| 4BPCA7.5/160-205/2200 | 205 | ＜450 | 160~420 | 2200 | 7.5 | 160.0 | 1.5" | 2 |
| 4BPCA7.5/210-300/3000-LV | 300 | ＜450 | 200~440 | 3000 | 7.5 | 210.0 | 2" | 2 |
| 4BPCA7.5/210-305/3000 | 305 | ＜450 | 200~440 | 3000 | 7.5 | 210.0 | 2" | 2 |
| 4BPCA9.0/30-48/600-LV | 48 | ＜105 | 40~90 | 600 | 9.0 | 30.0 | 2" | 2 |
| 4BPCA9.0/45-48/750-LV | 48 | ＜105 | 40~90 | 750 | 9.0 | 45.0 | 2" | 2 |
| 4BPCA9.0/65-110/1100-LV | 110 | ＜210 | 90~160 | 1100 | 9.0 | 65.0 | 2" | 2 |
| 4BPCA10.0/95-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 10.0 | 95.0 | 2" | 2 |
| 4BPCA10.0/95-125/1500 | 125 | ＜450 | 110~400 | 1500 | 10.0 | 95.0 | 2" | 2 |
| 4BPCA10.0/130-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 10.0 | 130.0 | 2" | 2 |
| 4BPCA10.0/130-205/2200 | 205 | ＜450 | 160~420 | 2200 | 10.0 | 130.0 | 2" | 2 |
| 4BPCA10.0/170-300/3000-LV | 300 | ＜450 | 200~440 | 3000 | 10.0 | 170.0 | 2" | 2 |
| 4BPCA10.0/170-305/3000 | 305 | ＜450 | 200~440 | 3000 | 10.0 | 170.0 | 2" | 2 |
| 4BPCA12.0/200-400/4000 | 400 | ＜780 | 260~700 | 4000 | 12.0 | 200.0 | 2" | 2 |
| 4BPCA13.0/30-48/750-LV | 48 | ＜105 | 40~90 | 750 | 13.0 | 30.0 | 2" | 2 |
| 4BPCA14.0/45-110/1100-LV | 110 | ＜210 | 90~160 | 1100 | 14.0 | 45.0 | 2" | 2 |
| 4BPCA14.5/70-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 14.5 | 70.0 | 2" | 2 |
| 4BPCA14.5/70-125/1500 | 125 | ＜450 | 110~400 | 1500 | 14.5 | 70.0 | 2" | 2 |
| 4BPCA14.5/100-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 14.5 | 100.0 | 2" | 2 |
| 4BPCA14.5/100-205/2200 | 205 | ＜450 | 160~420 | 2200 | 14.5 | 100.0 | 2" | 2 |
| 4BPCA14.5/120-300/3000-LV | 300 | ＜450 | 200~440 | 3000 | 14.5 | 120.0 | 2" | 2 |
| 4BPCA14.5/120-305/3000 | 305 | ＜450 | 200~440 | 3000 | 14.5 | 120.0 | 2" | 2 |
| 4BPCA16.5/160-400/4000 | 400 | ＜780 | 260~700 | 4000 | 16.5 | 160.0 | 2" | 2 |
| 4BPCA16.0/220-360/5500 | 360 | ＜780 | 200~700 | 5500 | 16.0 | 220.0 | 2" | 2 |
| 4BPCA20.0-45-120/1500-LV | 120 | ＜210 | 90~160 | 1500 | 20.0 | 45.0 | 2" | 2 |
| 4BPCA20.0-45-125/1500 | 125 | ＜450 | 110~400 | 1500 | 20.0 | 45.0 | 2" | 2 |
| 4BPCA20.0-65-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 20.0 | 65.0 | 2" | 2 |
| 4BPCA20.0-65-205/2200 | 205 | ＜450 | 160~420 | 2200 | 20.0 | 65.0 | 2" | 2 |
| 4BPCA20.0-75-300/3000-LV | 300 | ＜450 | 200~440 | 3000 | 20.0 | 75.0 | 2" | 2 |
| 4BPCA20.0-75-305/3000 | 305 | ＜450 | 200~440 | 3000 | 20.0 | 75.0 | 2" | 2 |
| 4BPCA19.0-125-400/4000 | 400 | ＜780 | 260~700 | 4000 | 19.0 | 125.0 | 2" | 2 |
| 4BPCA18.0-170-360/5500 | 360 | ＜780 | 200~700 | 5500 | 18.0 | 170.0 | 2" | 2 |
| 4BPCA18.0-230-400/7500 | 400 | ＜780 | 260~700 | 7500 | 18.0 | 230.0 | 2" | 2 |
| 4BPCA30.0-35-200/2200-LV | 200 | ＜450 | 160~420 | 2200 | 30.0 | 35.0 | 2" | 2 |
| 4BPCA30.0-35-205/2200 | 205 | ＜450 | 160~420 | 2200 | 30.0 | 35.0 | 2" | 2 |
| 4BPCA30.0/50-300/3000-LV | 300 | ＜450 | 200~440 | 3000 | 30.0 | 50.0 | 2" | 2 |
| 4BPCA30.0/50-305/3000 | 305 | ＜450 | 200~440 | 3000 | 30.0 | 50.0 | 2" | 2 |
| 4BPCA34.0/75-400/4000 | 400 | ＜780 | 260~700 | 4000 | 34.0 | 75.0 | 2" | 2 |
| 4BPCA33.0/100-360/5500 | 360 | ＜780 | 200~700 | 5500 | 33.0 | 100.0 | 2" | 2 |
| 4BPCA34.0/135-400/7500 | 400 | ＜780 | 260~700 | 7500 | 34.0 | 135.0 | 2" | 2 |
