Overview
The CODOL CQB Solar Peripheral Pump is a compact surface-mounted pump designed for clean water transfer and pressure boosting using solar energy. Equipped with an intelligent external MPPT controller and a permanent magnet brushless DC motor, it delivers stable performance while maximizing solar energy utilization. Its peripheral impeller design provides high pressure with moderate flow, making it ideal for residential and light agricultural applications.
Features
- Intelligent external MPPT controller
- Permanent magnet brushless DC motor
- Peripheral impeller hydraulic design
- High head with stable pressure
- Compact surface-mounted construction
- Dry-run and overload protection
- Easy installation and maintenance
- Long service life
Applications
- Household water supply
- Water pressure boosting
- Garden irrigation
- Water transfer
- Small farms
- Clean water circulation
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power(W) | Power(HP) | Max flow (m³/h) | Max head (m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|---|
| CQB1.3-16-12-150 | 12 | ＜55 | 18-45 | 150 | 0.1995 | 1.3 | 16 | 1"*1" | 1.2 |
| CQB2.0-28-24-250 | 24 | ＜55 | 18-45 | 250 | 0.3325 | 2 | 28 | 1"*1" | 1.2 |
| CQB2.2-40-48-400 | 48 | ＜105 | 40-90 | 400 | 0.532 | 2.2 | 40 | 1"*1" | 1.2 |
