Overview
The CODOL CDSU Solar Centrifugal Pump is engineered for large-volume water transfer and agricultural irrigation. Equipped with an intelligent external MPPT controller and a high-efficiency permanent magnet brushless DC motor, it provides reliable pumping performance for rivers, reservoirs, ponds and irrigation systems while reducing energy costs.
Features
- Intelligent external MPPT controller
- Permanent magnet brushless DC motor
- High-flow centrifugal hydraulic design
- Surface-mounted installation
- Excellent energy efficiency
- Dry-run protection
- Reliable continuous operation
- Easy installation and maintenance
Applications
- Agricultural irrigation
- Farmland irrigation
- River water pumping
- Reservoir water transfer
- Fish ponds
- Water storage systems
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power(W) | Power(HP) | Max flow (m³/h) | Max head (m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|---|
| CDSU17-14-144-1100 | 144 | ＜450 | 130~400 | 1100 | 1.463 | 17 | 14 | 2"*2" | 1.2 |
| CDSU18-22-192-1500 | 192 | ＜450 | 140~400 | 1500 | 1.995 | 18 | 22 | 2"*2" | 1.2 |
| CDSU45-19-280-2200 | 280 | ＜450 | 180~430 | 2200 | 3.026 | 45 | 19 | 3"*3" | 1.2 |
| CDSU20-18-110-1100-2LV | 110 | ＜210 | 90~160 | 1100 | 1.5 | 20 | 18 | 2"*2" | 1.2 |
| CDSU25-20-120-1500-2LV | 120 | ＜210 | 90~160 | 1500 | 2 | 25 | 20 | 2"*2" | 1.2 |
| CDSU25-25-200-2200-2LV | 200 | ＜450 | 160~420 | 2200 | 3 | 25 | 25 | 2"*2" | 1.2 |
| CDSU35-15-110-1100-3LV | 110 | ＜210 | 90~160 | 1100 | 1.5 | 35 | 15 | 3"*3" | 1.2 |
| CDSU45-18-120-1500-3LV | 120 | ＜210 | 90~160 | 1500 | 2 | 45 | 18 | 3"*3" | 1.2 |
| CDSU50-25-200-2200-3LV | 200 | ＜450 | 160~420 | 2200 | 3 | 50 | 25 | 3"*3" | 1.2 |
| CDSU52-30-300-3000-3LV | 300 | ＜450 | 200~440 | 3000 | 4 | 52 | 30 | 3"*3" | 1.2 |
| CDSU50-15-120-1500-4LV | 120 | ＜210 | 90~160 | 1500 | 2 | 50 | 15 | 4"*4" | 1.2 |
| CDSU60-20-200-2200-4LV | 200 | ＜450 | 160~420 | 2200 | 3 | 60 | 20 | 4"*4" | 1.2 |
| CDSU60-25-300-3000-4LV | 300 | ＜450 | 200~440 | 3000 | 4 | 60 | 25 | 4"*4" | 1.2 |
| CDSU145-16-400-4000 | 400 | ＜780 | 260~700 | 4000 | 5.5 | 145 | 16 | 6" | 1.2 |
| CDSU160-20-360-5500 | 360 | ＜780 | 200~700 | 5500 | 7.5 | 160 | 20 | 6" | 1.2 |
| CDSU160-30-400-7500 | 400 | ＜780 | 260~700 | 7500 | 10 | 160 | 30 | 6" | 1.2 |
