Overview
The CODOL BQDX Integrated Controller Solar Drainage Pump is designed for efficient drainage and clean water transfer using solar energy. With the controller integrated inside the pump, installation becomes faster while reducing external wiring and maintenance requirements.
Features
- Built-in intelligent MPPT controller
- No external controller required
- Direct solar panel connection
- Reliable drainage performance
- Dry-run protection
- Over-voltage and overload protection
- Compact and lightweight structure
- Easy installation and maintenance
Applications
- Water drainage
- Basement drainage
- Ponds and reservoirs
- Water transfer
- Agricultural drainage
- Emergency pumping
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power (W) | Max flow (m³/h) | Max head(m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|
| BQDX5.0/15-30/280-1 | 30 | <55 | 18~45 | 280 | 5.0 | 15.0 | 1" | 10 |
| BQDX5.5/20-48/400-1 | 48 | <105 | 40~90 | 400 | 5.5 | 20.0 | 1" | 10 |
| BQDX6.5/20-72/600-1 | 72 | <160 | 60~120 | 600 | 6.5 | 20.0 | 1" | 10 |
| BQDX7.0/26-48/750-1 | 48 | <105 | 40~90 | 750 | 7.0 | 26.0 | 1" | 10 |
| BQDX7.0/26-96/750-1 | 96 | <210 | 80~150 | 750 | 7.0 | 26.0 | 1" | 10 |
| BQDX13.0/20-72/600-2 | 72 | <160 | 60~120 | 600 | 13.0 | 20.0 | 2" | 10 |
| BQDX14.0/23-48/750-2 | 48 | <105 | 40~90 | 750 | 14.0 | 23.0 | 2" | 10 |
| BQDX14.0/23-96/750-2 | 96 | <210 | 80~150 | 750 | 14.0 | 23.0 | 2" | 10 |
| BQDX16.0/25-72/1100-2 | 72 | <160 | 60~120 | 1100 | 16.0 | 25.0 | 2" | 10 |
| BQDX17.0/30-72/1300-2 | 72 | <160 | 60~120 | 1300 | 17.0 | 30.0 | 2" | 10 |
| BQDX30.0/8-48/750-3 | 48 | <105 | 40~90 | 750 | 30.0 | 8.0 | 3" | 10 |
| BQDX30.0/8-96/750-3 | 96 | <210 | 80~150 | 750 | 30.0 | 8.0 | 3" | 10 |
| BQDX36.0/10-72/1100-3 | 72 | <160 | 60~120 | 1100 | 36.0 | 10.0 | 3" | 10 |
| BQDX40.0/12-72/1300-3 | 72 | <160 | 60~120 | 1300 | 40.0 | 12.0 | 3" | 10 |
| BQDX30.0/7-48/750-4 | 48 | <105 | 40~90 | 750 | 30.0 | 7.0 | 4" | 10 |
| BQDX39.0/7-96/750-4 | 96 | <210 | 80~150 | 750 | 39.0 | 7.0 | 4" | 10 |
| BQDX33.0/9-72/1100-4 | 72 | <160 | 60~120 | 1100 | 33.0 | 9.0 | 4" | 10 |
| BQDX40.0/10-72/1300-4 | 72 | <160 | 60~120 | 1300 | 40.0 | 10.0 | 4" | 10 |
| BQDX5.0/15-30/280-1LV | 30 | <55 | 18~45 | 280 | 5.0 | 15.0 | 1" | 10 |
| BQDX5.5/20-48/400-1LV | 48 | <105 | 40~90 | 400 | 5.5 | 20.0 | 1" | 10 |
| BQDX6.5/20-48/600-1LV | 48 | <105 | 40~90 | 600 | 6.5 | 20.0 | 1" | 10 |
| BQDX7.0/26-48/750-1LV | 48 | <105 | 40~90 | 750 | 7.0 | 26.0 | 1" | 10 |
| BQDX13.0/20-48/600-2LV | 48 | <105 | 40~90 | 600 | 13.0 | 20.0 | 2" | 10 |
| BQDX14.0/23-48/750-2LV | 48 | <105 | 40~90 | 750 | 14.0 | 23.0 | 2" | 10 |
| BQDX16.0/25-110/1100-2LV | 110 | <210 | 90~160 | 1100 | 16.0 | 25.0 | 2" | 10 |
| BQDX17.0/30-120/1500-2LV | 120 | <210 | 90~160 | 1500 | 17.0 | 30.0 | 2" | 10 |
| BQDX30.0/8-48/750-3LV | 48 | <105 | 40~90 | 750 | 30.0 | 8.0 | 3" | 10 |
| BQDX36.0/10-110/1100-3LV | 110 | <210 | 90~160 | 1100 | 36.0 | 10.0 | 3" | 10 |
| BQDX40.0/12-120/1500-3LV | 120 | <210 | 90~160 | 1500 | 40.0 | 12.0 | 3" | 10 |
| BQDX30.0/7-48/750-4LV | 48 | <105 | 40~90 | 750 | 30.0 | 7.0 | 4" | 10 |
| BQDX33.0/9-110/1100-4LV | 110 | <210 | 90~160 | 1100 | 39.0 | 7.0 | 4" | 10 |
| BQDX40.0/10-120/1500-4LV | 120 | <210 | 90~160 | 1500 | 40.0 | 10.0 | 4" | 10 |
