Overview
The CODOL BDSU Integrated Controller Solar Surface Pump is developed for high-capacity agricultural irrigation and water transfer applications. With an intelligent MPPT controller integrated into the pump, it simplifies system installation while maximizing solar energy utilization. The surface-mounted design makes it ideal for pumping water from rivers, canals, reservoirs and storage ponds.
Features
- Built-in intelligent MPPT controller
- High-flow centrifugal hydraulic design
- Surface-mounted installation
- Direct solar panel connection
- No external controller box required
- Dry-run, overload and over-voltage protection
- Stable and reliable operation
- Low maintenance requirements
Applications
- Agricultural irrigation
- Large farmland irrigation
- River water pumping
- Canal water transfer
- Reservoir water supply
- Fish ponds and aquaculture
- Large-volume clean water transfer
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power (W) | Max flow (m³/h) | Max head(m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|
| BDSU20/18-110/1100-2-LV | 110 | <210 | 90~160 | 1100 | 20.0 | 18.0 | 2" | 1 |
| BDSU25/20-120/1500-2-LV | 120 | <210 | 90~160 | 1500 | 25.0 | 20.0 | 2" | 1 |
| BDSU25/25-200/2200-2-LV | 200 | <450 | 160~420 | 2200 | 25.0 | 25.0 | 2" | 1 |
| BDSU35/15-110/1100-3-LV | 110 | <210 | 90~160 | 1100 | 35.0 | 15.0 | 3" | 1 |
| BDSU45/18-120/1500-3-LV | 120 | <210 | 90~160 | 1500 | 45.0 | 18.0 | 3" | 1 |
| BDSU50/25-200/2200-3-LV | 200 | <450 | 160~420 | 2200 | 50.0 | 25.0 | 3" | 1 |
| BDSU52/30-300/3000-3-LV | 300 | <450 | 200~400 | 3000 | 52.0 | 30.0 | 3" | 1 |
| BDSU50/15-120/1500-4-LV | 120 | <210 | 90~160 | 1500 | 50.0 | 15.0 | 4" | 1 |
| BDSU60/20-200/2200-4-LV | 200 | <450 | 160~420 | 2200 | 60.0 | 20.0 | 4" | 1 |
| BDSU60/25-300/3000-4-LV | 300 | <450 | 200~400 | 3000 | 60.0 | 25.0 | 4" | 1 |
