Overview
The CODOL CSPM Hybrid AC/DC Solar Peripheral Pump delivers stable water pressure using both solar and AC power. The intelligent hybrid controller automatically switches between available power sources, providing reliable operation throughout the day while reducing electricity consumption.
Features
- Intelligent hybrid controller
- Automatic solar and AC switching
- High-head peripheral hydraulic design
- Permanent magnet brushless DC motor
- Stable pressure output
- Dry-run protection
- Easy installation
- Long service life
Applications
- Household water supply
- Water pressure boosting
- Garden irrigation
- Villas
- Small farms
- Clean water transfer
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power(W) | Power(HP) | Max flow (m³/h) | Max head (m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|---|
| CSPM14-13-72-600-AC/DC | 72 | 90~240 | 50~400 | 600 | 0.798 | 14 | 13 | Φ50 | 1.2 |
| CSPM16-14-96-750-AC/DC | 96 | 90~240 | 50~400 | 750 | 0.9975 | 16 | 14 | Φ50 | 1.2 |
| CSPM22-13-144-1100-AC/DC | 144 | 90~240 | 50~400 | 1100 | 1.463 | 22 | 13 | Φ50 | 1.2 |
| CSPM25-14-192-1500-AC/DC | 192 | 90~240 | 50~400 | 1500 | 1.995 | 25 | 14 | Φ50 | 1.2 |
| CSPM36-18-280-2200-AC/DC | 280 | 90~240 | 50~400 | 2200 | 3.026 | 36 | 18 | Φ50 | 1.2 |
| CSPM14-13-72-600-AC/DCLV | 72 | 90~240 | 50~400 | 600 | 0.798 | 14 | 13 | Φ50 | 1.2 |
| CSPM16-14-96-750-AC/DCLV | 96 | 90~240 | 50~400 | 750 | 0.9975 | 16 | 14 | Φ50 | 1.2 |
| CSPM22-13-115-1100-AC/DCLV | 115 | 90~240 | 50~400 | 1100 | 1.463 | 22 | 13 | Φ50 | 1.2 |
| CSPM25-14-125-1500-AC/DCLV | 125 | 90~240 | 50~400 | 1500 | 1.995 | 25 | 14 | Φ50 | 1.2 |
| CSPM36-18-205-2200-AC/DCLV | 205 | 90~240 | 50~400 | 2200 | 3.026 | 36 | 18 | Φ50 | 1.2 |
