Overview
The CODOL CDSU Hybrid AC/DC Solar Centrifugal Pump is designed for demanding agricultural irrigation and large-volume water transfer applications. By combining solar energy with AC backup power, it ensures continuous irrigation even during cloudy weather or at night.
Features
- Intelligent hybrid AC/DC controller
- Automatic solar priority
- High-flow centrifugal hydraulic system
- Surface-mounted construction
- Permanent magnet brushless DC motor
- Dry-run protection
- Stable continuous operation
- Easy maintenance
Applications
- Agricultural irrigation
- River water pumping
- Reservoir water transfer
- Fish ponds
- Farmland irrigation
- Water storage systems
Specifications
| Model | Voltage (V) | Max Input Voltage VOC | Best Input Voltage VOC | Power(W) | Power(HP) | Max flow (m³/h) | Max head (m) | Outlet (Inch) | Cable (m) |
|---|---|---|---|---|---|---|---|---|---|
| CDSU20-18-110-1100-2AC/DC | 110 | 90~240 | 50~400 | 1100 | 1.5 | 20 | 18 | 2"*2" | 1.2 |
| CDSU25-20-120-1500-2AC/DC | 120 | 90~240 | 50~400 | 1500 | 2 | 25 | 20 | 2"*2" | 1.2 |
| CDSU25-25-200-2200-2AC/DC | 200 | 90~240 | 50~400 | 2200 | 3 | 25 | 25 | 2"*2" | 1.2 |
| CDSU35-15-110-1100-3AC/DC | 110 | 90~240 | 50~400 | 1100 | 1.5 | 35 | 15 | 3"*3" | 1.2 |
| CDSU45-18-120-1500-3AC/DC | 120 | 90~240 | 50~400 | 1500 | 2 | 45 | 18 | 3"*3" | 1.2 |
| CDSU50-25-200-2200-3AC/DC | 200 | 90~240 | 50~400 | 2200 | 3 | 50 | 25 | 3"*3" | 1.2 |
| CDSU52-30-300-3000-3AC/DC | 300 | 90~240 | 50~400 | 3000 | 4 | 52 | 30 | 3"*3" | 1.2 |
| CDSU50-15-120-1500-4AC/DC | 120 | 90~240 | 50~400 | 1500 | 2 | 50 | 15 | 4"*4" | 1.2 |
| CDSU60-20-200-2200-4AC/DC | 200 | 90~240 | 50~400 | 2200 | 3 | 60 | 20 | 4"*4" | 1.2 |
| CDSU60-25-300-3000-4AC/DC | 300 | 90~240 | 50~400 | 3000 | 4 | 60 | 25 | 4"*4" | 1.2 |
| CDSU20-18-115-1100-2AC/DCLV | 115 | 90~240 | 50~400 | 1100 | 1.5 | 20 | 18 | 2"*2" | 1.2 |
| CDSU25-20-125-1500-2AC/DCLV | 125 | 90~240 | 50~400 | 1500 | 2 | 25 | 20 | 2"*2" | 1.2 |
| CDSU25-25-205-2200-2AC/DCLV | 205 | 90~240 | 50~400 | 2200 | 3 | 25 | 25 | 2"*2" | 1.2 |
| CDSU35-15-115-1100-3AC/DCLV | 115 | 90~240 | 50~400 | 1100 | 1.5 | 35 | 15 | 3"*3" | 1.2 |
| CDSU45-18-125-1500-3AC/DCLV | 125 | 90~240 | 50~400 | 1500 | 2 | 45 | 18 | 3"*3" | 1.2 |
| CDSU50-25-205-2200-3AC/DCLV | 205 | 90~240 | 50~400 | 2200 | 3 | 50 | 25 | 3"*3" | 1.2 |
| CDSU52-30-305-3000-3AC/DCLV | 305 | 90~240 | 50~400 | 3000 | 4 | 52 | 30 | 3"*3" | 1.2 |
| CDSU50-15-125-1500-4AC/DCLV | 125 | 90~240 | 50~400 | 1500 | 2 | 50 | 15 | 4"*4" | 1.2 |
| CDSU60-20-205-2200-4AC/DCLV | 205 | 90~240 | 50~400 | 2200 | 3 | 60 | 20 | 4"*4" | 1.2 |
| CDSU60-25-305-3000-4AC/DCLV | 305 | 90~240 | 50~400 | 3000 | 4 | 60 | 25 | 4"*4" | 1.2 |
| CDSU140-16-400-4000-6AC/DC380AC/DCLV | 400 | 200~440 | 260~700 | 4000 | 5.5 | 140 | 16 | 6" | 1.2 |
| CDSU160-20-360-5500-6AC/DC380AC/DCLV | 360 | 200~440 | 200~700 | 5500 | 7 | 160 | 20 | 6" | 1.2 |
| CDSU160-30-400-7500-6AC/DC380AC/DCLV | 400 | 200~440 | 200~700 | 7500 | 10 | 160 | 30 | 6" | 1.2 |
