4SP(m)

Overview

The CODOL 4SP Stainless Steel Deep Well Submersible Pump is designed for reliable water extraction from deep wells, reservoirs, and underground water sources. Its fully stainless steel hydraulic construction provides excellent corrosion resistance, high efficiency, and long service life. Engineered for continuous operation, the 4SP series delivers stable performance for residential, agricultural, commercial, and industrial water supply systems.

---

Features

• 4-inch deep well submersible pump
• Full stainless steel hydraulic construction for maximum corrosion resistance
• High-efficiency hydraulic design
• Stable performance with low energy consumption
• Rewindable motor for convenient maintenance
• Available in single-phase and three-phase configurations
• Compatible with external control box or automatic controller
• Reliable mechanical seal for extended service life
• Easy installation and maintenance

---

Applications

The 4SP series is suitable for pumping clean water in a variety of applications, including:

• Domestic water supply
• Deep well water extraction
• Agricultural irrigation
• Garden irrigation
• Water supply from reservoirs
• Commercial water supply
• Industrial water transfer
• Pressure boosting systems

---

Specifications

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7	3
					l/min	0	5	10	15	20	25	30	35	40	45	50
4SPM2-6	4SP2-6	0.37	0.5	H(m)		36	35	34	32	31	28	25	21	16	11	6
4SPM2-9	4SP2-9	0.37	0.5			54	53	51	48	46	42	37	31	25	17	9
4SPM2-13	4SP2-13	0.55	0.75			78	76	73	70	66	61	54	45	35	24	13
4SPM2-18	4SP2-18	0.75	1			108	105	102	97	92	85	75	63	49	34	18
4SPM2-23	4SP2-23	1.1	1.5			138	134	130	124	117	108	96	80	63	43	23
4SPM2-28	4SP2-28	1.3	1.75			168	164	158	151	143	132	116	97	76	53	28
4SPM2-33	4SP2-33	1.5	2			198	193	186	178	168	155	137	115	90	62	32
4SPM2-40	4SP2-40	1.8	2.5			240	234	226	215	204	188	166	139	109	75	39
4SPM2-48	4SP2-48	2.2	3			288	281	271	258	244	226	199	167	131	90	47
4SPM2-55	4SP2-55	2.6	3.5			330	322	311	296	280	259	228	191	150	103	54
4SPM2-65	4SP2-65	3	4			390	380	367	350	331	306	270	226	177	122	64

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	0.6	1.2	1.8	2.4	3	3.6	4.2
					l/min	0	10	20	30	40	50	60	70
4SPM3-6	4SP3-6	0.37	0.5	H(m)		37	36	34	32	29	26	21	15
4SPM3-9	4SP3-9	0.55	0.75			56	54	51	48	44	39	32	23
4SPM3-12	4SP3-12	0.75	1			74	71	68	64	59	52	43	31
4SPM3-15	4SP3-15	0.92	1.25			93	89	85	80	73	65	53	39
4SPM3-18	4SP3-18	1.1	1.5			112	107	102	96	88	78	64	46
4SPM3-22	4SP3-22	1.3	1.75			136	131	125	117	108	95	78	57
4SPM3-25	4SP3-25	1.5	2			155	149	142	133	122	108	89	65
4SPM3-29	4SP3-29	1.8	2.5			180	173	164	154	142	126	103	75
4SPM3-33	4SP3-33	2.2	3			205	196	187	175	162	143	118	85
4SPM3-39	4SP3-39	2.6	3.5			242	232	221	207	191	169	139	101
4SPM3-45	4SP3-45	3	4			279	268	255	239	220	195	160	116
-	4SP3-52	3.7	5			322	309	295	276	255	225	185	134
-	4SP3-60	4	5.5			372	357	340	319	294	260	214	155

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	0.6	1.2	1.8	2.4	3	3.6	4.2	4.8	5.4	6	6.6
					l/min	0	10	20	30	40	50	60	70	80	90	100	110
4SPM5-4	4SP5-4	0.37	0.5	H(m)		25	24	23	22	21	20	19	18	16	15	12	10
4SPM5-6	4SP5-6	0.55	0.75			37	36	35	33	32	30	28	26	24	22	19	15
4SPM5-8	4SP5-8	0.75	1			49	48	46	44	42	40	38	35	32	29	25	20
4SPM5-12	4SP5-12	1.1	1.5			74	72	69	66	63	60	57	53	48	44	37	31
4SPM5-15	4SP5-15	1.3	1.75			92	89	86	83	79	75	71	66	61	55	47	38
4SPM5-17	4SP5-17	1.5	2			105	101	98	94	90	85	80	75	69	62	53	44
4SPM5-21	4SP5-21	1.8	2.5			129	125	121	116	111	105	99	92	85	76	66	54
4SPM5-25	4SP5-25	2.2	3			154	149	144	138	132	125	118	110	101	91	78	64
4SPM5-29	4SP5-29	2.6	3.5			179	173	167	160	153	145	137	128	117	106	90	74
4SPM5-33	4SP5-33	3	4			203	197	190	182	174	165	156	145	133	120	103	84
-	4SP5-38	3.7	5			234	226	219	210	201	190	179	167	154	138	119	97
-	4SP5-44	4	5.5			271	262	253	243	232	220	208	194	178	160	137	112
-	4SP5-52	5	7			320	310	300	287	275	260	245	229	210	189	162	133
-	4SP5-58	5.5	7.5			357	346	334	320	306	290	274	255	234	211	181	148

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	1.2	2.4	3.6	4.8	6	7.2	8.4	9.6	10.8
					l/min	0	20	40	60	80	100	120	140	160	180
4SPM8-5	4SP8-5	0.75	1	H(m)		30	28	27	26	25	24	22	20	17	13
4SPM8-7	4SP8-7	1.1	1.5			42	40	38	37	35	33	31	28	24	18
4SPM8-10	4SP8-10	1.5	2			59	57	55	52	50	47	44	40	34	25
4SPM8-12	4SP8-12	1.8	2.5			71	68	66	63	60	57	53	48	41	30
4SPM8-15	4SP8-15	2.2	3			89	85	82	79	75	71	66	60	51	38
4SPM8-18	4SP8-18	3	4			107	102	98	94	90	85	79	72	61	46
-	4SP8-21	3.7	5			125	119	115	110	105	100	92	84	71	53
-	4SP8-25	4	5.5			149	142	137	131	125	118	110	99	85	63
-	4SP8-30	5	7			178	170	164	157	150	142	132	119	102	76
-	4SP8-36	5.5	7.5			214	204	197	189	180	171	158	143	122	91

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	1.8	3.6	5.4	7.2	9	10.8	12.6	14.4	16.2	18
					l/min	0	30	60	90	120	150	180	210	240	270	300
4SPM14-4	4SP14-4	1.3	1.75	H(m)		26	25	24	23	22	21	20	18	16	14	11
4SPM14-5	4SP14-5	1.5	2			32	31	29	28	27	26	24	23	20	18	14
4SPM14-6	4SP14-6	1.8	2.5			38	37	35	34	32	31	29	27	24	21	17
4SPM14-7	4SP14-7	2.2	3			45	43	41	39	38	36	34	32	28	25	20
4SPM14-8	4SP14-8	2.6	3.5			51	49	47	45	43	41	39	36	32	28	23
4SPM14-10	4SP14-10	3	4			64	62	59	56	54	51	49	45	40	35	28
-	4SP14-13	4	5.5			83	80	76	73	70	67	63	59	53	46	37
-	4SP14-16	5	7			102	99	94	90	86	82	78	73	65	57	45
-	4SP14-18	5.5	7.5			115	111	106	101	97	92	88	82	73	64	51
-	4SP14-22	7.5	10			140	135	129	124	118	113	107	100	90	78	62
-	4SP14-24	7.5	10			153	148	141	135	129	123	117	109	97	85	68
