3SD(m)

Overview

The CODOL 3SD Stainless Steel Deep Well Submersible Pump is designed for reliable clean water extraction from deep wells, reservoirs, and underground water sources. Its 3-inch slim construction allows installation in small-diameter wells while delivering stable water pressure and efficient performance. Built with corrosion-resistant stainless steel components, the 3SD series provides dependable operation and long service life for residential, agricultural, and light commercial water supply systems.

---

Features

• Slim 3-inch deep well submersible pump
• Stainless steel construction for excellent corrosion resistance
• High-efficiency hydraulic design
• Rewindable motor for convenient maintenance
• Available in single-phase and three-phase versions
• Compatible with external control box or automatic controller
• Reliable mechanical seal for long service life
• Compact design for easy installation in narrow wells

---

Applications

The 3SD series is suitable for pumping clean water in a variety of applications, including:

• Domestic water supply
• Deep well water extraction
• Garden irrigation
• Agricultural irrigation
• Water transfer from reservoirs
• Civil water supply systems
• Light industrial water supply
• Small pressure boosting systems

---

Specifications

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	0.3	0.6	0.9	1.2	1.5	1.8	2.1	2.4	2.7
					l/min	0	5	10	15	20	25	30	35	40	45
3SDM2/8	3SD2/8	0.18	0.25	H(m)		34	34	33	33	31	29	26	23	19	14
3SDM2/11	3SD2/11	0.25	0.33			47	46	45	45	43	40	36	32	27	20
3SDM2/15	3SD2/15	0.37	0.5			64	63	62	61	58	54	49	43	36	27
3SDM2/21	3SD2/21	0.55	0.75			89	89	87	85	81	76	68	60	51	38
3SDM2/27	3SD2/27	0.75	1			115	114	112	110	104	97	88	77	65	49
3SDM2/33	3SD2/33	0.92	1.25			141	139	136	134	128	119	108	95	80	60
3SDM2/39	3SD2/39	1.1	1.5			166	164	161	159	151	141	127	112	94	70
3SDM2/46	3SD2/46	1.5	2			196	194	190	187	178	166	150	132	111	83

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	0.6	1.2	1.8	2.4	3	3.6	3.9
					l/min	0	10	20	30	40	50	60	65
3SDM3/6	3SD3/6	0.18	0.25	H(m)		24	23	22	21	19	15	10	7
3SDM3/8	3SD3/8	0.25	0.33			32	31	30	28	25	20	13	9
3SDM3/11	3SD3/11	0.37	0.5			44	43	41	39	35	28	18	12
3SDM3/16	3SD3/16	0.55	0.75			64	63	60	57	51	41	26	17
3SDM3/21	3SD3/21	0.75	1			84	82	78	74	67	53	34	23
3SDM3/26	3SD3/26	0.92	1.25			104	102	97	92	83	66	43	28
3SDM3/31	3SD3/31	1.1	1.5			124	121	116	110	99	79	51	34
3SDM3/37	3SD3/37	1.5	2			148	145	138	131	118	94	61	40

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	0.6	1.2	1.8	2.4	3	3.6	4.2	4.8	5.4
					l/min	0	10	20	30	40	50	60	70	80	90
3SDM4/6	3SD4/6	0.25	0.33	H(m)		25	25	24	23	22	21	19	16	13	8
3SDM4/9	3SD4/9	0.37	0.5			37	37	36	35	33	32	28	24	19	12
3SDM4/12	3SD4/12	0.55	0.75			49	49	48	47	45	42	37	32	25	15
3SDM4/16	3SD4/16	0.75	1			66	66	65	62	59	56	50	42	34	21
3SDM4/20	3SD4/20	0.92	1.25			82	82	81	78	74	70	62	53	42	25
3SDM4/24	3SD4/24	1.1	1.5			99	99	97	93	89	84	75	63	51	31
3SDM4/28	3SD4/28	1.5	2			115	115	113	109	104	98	87	74	59	36

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	1.2	2.4	3.6	4.8	6	7.2	8.4
					l/min	0	20	40	60	80	100	120	140
3SDM6/4	3SD6/4	0.25	0.33	H(m)		16	16	15	14	12	10	8	5
3SDM6/6	3SD6/6	0.37	0.5			24	23	22	20	18	15	12	8
3SDM6/8	3SD6/8	0.55	0.75			32	31	30	27	24	20	16	10
3SDM6/11	3SD6/11	0.75	1			43	43	41	37	33	28	22	14
3SDM6/14	3SD6/14	0.92	1.25			55	55	52	48	42	36	28	18
3SDM6/17	3SD6/17	1.1	1.5			67	66	63	58	51	43	34	21
3SDM6/20	3SD6/20	1.5	2			79	78	74	68	60	51	40	25
