Overview
The CODOL ZBP Variable Frequency Constant Pressure Self-Priming Pump is an intelligent pressure boosting solution designed for modern household water systems. With an integrated inverter controller and permanent magnet motor, it automatically adjusts operating speed according to water demand, maintaining constant pressure while significantly reducing energy consumption.
Its compact design, quiet operation, and reliable self-priming capability make it ideal for villas, apartments, water tanks, rooftop water supply, and other domestic water pressure boosting applications.
Features
- Built-in variable frequency controller for intelligent pressure control
- Permanent magnet motor with high efficiency and energy saving
- Stable constant pressure water supply
- Self-priming capability for suction applications
- FOC motor control technology for smooth and efficient operation
- Ultra-low standby power consumption (as low as 1W)
- Ceramic shaft for excellent wear and corrosion resistance
- Low-noise operation for comfortable residential use
- LCD display for convenient monitoring and operation
- Integrated pressure sensor and check valve
- Compact size for easy installation and maintenance
Applications
Suitable for:
- Household water pressure boosting
- Main pipeline pressure boosting
- Water tank boosting
- Rooftop water supply
- Garden irrigation
- Small commercial water supply
- Villas and apartments
- Swimming pools requiring suction lift
- Domestic water systems with unstable pressure
Specifications
| Model | Power (W) | Power (HP) | Max Flow (m3/h) | Max Head (m) | Rated Flow (m3/h) | Rated Head (m) | Suction Lift (m) | Max Speed (R/min) | Connection Size (Inch) |
|---|---|---|---|---|---|---|---|---|---|
| ZBP1.5-20 | 280 | 0.37 | 3.7 | 30 | 1.5 | 20 | 4 | 5800 | 1" |
| ZBP2-20 | 380 | 0.5 | 4.5 | 33 | 2 | 20 | 4 | 6000 | 1" |
| ZBP2-30 | 500 | 0.67 | 4.8 | 35 | 2 | 30 | 4 | 6200 | 1" |
