Overview
The CODOL CHM Horizontal Multistage Centrifugal Pump is designed for high-pressure clean water transfer and pressure boosting in residential, commercial, and industrial applications. Its horizontal multistage construction provides high efficiency, stable pressure, and reliable operation while allowing for easy installation and maintenance. Manufactured with corrosion-resistant stainless steel hydraulic components, the CHM series delivers excellent durability and long service life in demanding water supply systems.
Features
- Horizontal multistage design for high-pressure applications
- Compact structure with easy installation and maintenance
- Stainless steel pump chamber for excellent corrosion resistance
- High hydraulic efficiency with stable water pressure
- Low vibration and quiet operation
- Reliable mechanical seal for long service life
- Available in single-phase and three-phase configurations
- Suitable for continuous operation
Applications
The CHM series is suitable for transporting clean water and non-aggressive liquids in a wide range of applications, including:
- Domestic water supply
- Pressure boosting systems
- Commercial buildings
- Industrial water circulation
- HVAC and cooling systems
- Irrigation systems
- Firefighting booster systems
- Water treatment equipment
- Boiler water supply
- Reverse osmosis systems
Specifications
| MODEL | VOLTAGE | POWER (KW) | POWER (HP) | RATED.FLOW (m³/h) | RATED.HEAD (m) | MAX.SUCT (m) | INLET/OUTLET (inch) |
|---|---|---|---|---|---|---|---|
| CHM2-9*2 | 220V/50HZ | 0.37 | 0.5 | 2 | 18 | 8 | 1*1 |
| CHM2-9*3 | 220V/50HZ | 0.55 | 0.75 | 2 | 27 | 8 | 1*1 |
| CHM2-9*4 | 220V/50HZ | 0.75 | 1 | 2 | 36 | 8 | 1*1 |
| CHM2-9*5 | 220V/50HZ | 1 | 1.5 | 2 | 45 | 8 | 1*1 |
| CHM2-9*6 | 220V/50HZ | 1 | 1.5 | 2 | 54 | 8 | 1*1 |
| CHM4-9*2 | 220V/50HZ | 0.55 | 0.75 | 4 | 18 | 8 | 1*1 |
| CHM4-9*3 | 220V/50HZ | 0.75 | 1 | 4 | 27 | 8 | 1*1 |
| CHM4-9*4 | 220V/50HZ | 1 | 1.35 | 4 | 36 | 8 | 1*1 |
| CHM4-9*5 | 220V/50HZ | 1.5 | 2 | 4 | 45 | 8 | 1*1 |
| CHM4-9*6 | 220V/50HZ | 1.5 | 2 | 4 | 54 | 8 | 1*1 |
| CHM6-8.5*3 | 220V/50HZ | 1.1 | 1.5 | 6 | 26 | 8 | 1.25*1.25 |
| CHM6-8.5*4 | 220V/50HZ | 1.5 | 2 | 6 | 34 | 8 | 1.25*1.25 |
| CHM6-8.5*5T | 380V/50HZ | 2.2 | 3 | 6 | 43 | 8 | 1.25*1.25 |
| CHM6-8.5*6T | 380V/50HZ | 2.2 | 3 | 6 | 51 | 8 | 1.25*1.25 |
| CHM8-9*2 | 220V/50HZ | 1.1 | 1.5 | 8 | 18 | 8 | 1.5*1.25 |
| CHM8-9*3 | 220V/50HZ | 1.1 | 1.5 | 8 | 27 | 8 | 1.5*1.25 |
| CHM8-9*4 | 220V/50HZ | 1.5 | 2 | 8 | 36 | 8 | 1.5*1.25 |
| CHM8-9*5 | 220V/50HZ | 2.2 | 3 | 8 | 45 | 8 | 1.5*1.25 |
| CHM12-8.5*2 | 220V/50HZ | 1.1 | 1.5 | 12 | 17 | 8 | 1.5*1.25 |
| CHM12-8.5*3 | 220V/50HZ | 1.5 | 2 | 12 | 25 | 8 | 1.5*1.25 |
| CHM12-8.5*4 | 220V/50HZ | 2.2 | 3 | 12 | 34 | 8 | 1.5*1.25 |
