5SD(m)/5SS(m)

Overview

The CODOL 5SD and 5SS Stainless Steel Deep Well Submersible Pumps are designed for efficient water extraction from deep wells, reservoirs, and underground water sources. Engineered with corrosion-resistant stainless steel construction, these pumps provide reliable performance, high efficiency, and long service life under continuous operation. The 5-inch design makes them suitable for a wide range of residential, agricultural, commercial, and industrial water supply applications.

---

Features

• 5-inch deep well submersible pump
• Stainless steel construction for excellent corrosion resistance
• High-efficiency hydraulic design
• Stable performance with low energy consumption
• Rewindable motor for convenient maintenance
• Available in single-phase and three-phase configurations
• Compatible with external control box or automatic controller
• Reliable mechanical seal for extended service life
• Easy installation and maintenance

---

Applications

The 5SD and 5SS series are suitable for pumping clean water in a wide range of applications, including:

• Domestic water supply
• Deep well water extraction
• Agricultural irrigation
• Garden irrigation
• Water supply from reservoirs
• Civil water supply systems
• Commercial water supply
• Industrial water transfer
• Pressure boosting systems

---

Specifications

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	1.8	3.6	5.4	7.2	9	10.8	12.6	14.4
					l/min	0	30	60	90	120	150	180	210	240
5SDM10/6	5SD10/6	1.5	2	H(m)		63	63	62	59	55	49	40	29	16
5SDM10/8	5SD10/8	2.2	3			84	84	83	79	73	65	53	38	22
5SDM10/10	5SD10/10	3	4			105	105	103	99	91	81	67	48	27
5SDM10/13	5SD10/13	4	5.5			136	137	134	128	119	105	87	62	35
-	5SD10/17	5.5	7.5			178	179	176	168	155	138	113	81	46
-	5SD10/21	7.5	10			220	221	217	207	192	170	140	101	57
-	5SD10/25	9.2	12.5			262	263	259	247	228	203	166	120	68
-	5SD10/29	11	15			304	305	300	286	265	235	193	139	79

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	2.4	4.8	7.2	9.6	12	14.4	16.8	19.2
					l/min	0	40	80	120	160	200	240	280	320
5SDM15/4	5SD15/4	1.5	2	H(m)		43	44	43	41	38	34	29	22	13
5SDM15/5	5SD15/5	2.2	3			54	55	54	51	48	43	36	27	17
5SDM15/7	5SD15/7	3	4			76	77	75	72	67	60	50	38	23
5SDM15/9	5SD15/9	4	5.5			97	99	97	92	86	78	65	48	30
-	5SD15/12	5.5	7.5			130	131	129	123	115	103	86	65	40
-	5SD15/15	7.5	10			162	164	161	154	144	129	108	81	50
-	5SD15/18	9.2	12.5			195	197	194	184	172	155	129	97	60
-	5SD15/21	11	15			227	230	226	215	201	181	151	113	70

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	3	6	9	12	15	18	21	24	27
					l/min	0	50	100	150	200	250	300	350	400	450
5SDM22/4	5SD22/4	2.2	3	H(m)		43	41	40	38	36	34	31	26	21	14
5SDM22/5	5SD22/5	3	4			53	52	50	48	45	43	39	33	26	18
5SDM22/7	5SD22/7	4	5.5			75	73	70	67	64	60	54	46	36	25
-	5SD22/9	5.5	7.5			96	93	90	86	82	77	69	59	47	32
-	5SD22/11	7.5	10			117	114	110	105	100	94	85	72	57	39
-	5SD22/13	9.2	12.5			138	135	130	124	118	110	100	85	68	46
-	5SD22/16	11	15			170	166	160	153	145	136	123	105	83	57

MODEL		P2		DELIVERY n≈2850 1/min
1~ 220 - 240V	3~ 380 - 415V	kW	HP	Q	m³/h	0	6	12	18	24	30	36	42
					l/min	0	100	200	300	400	500	600	700
5SDM30/3	5SD30/3	2.2	3	H(m)		29	28	26	25	22	19	14	9
5SDM30/4	5SD30/4	3	4			39	38	35	33	29	25	19	12
5SDM30/5	5SD30/5	4	5.5			49	47	44	41	36	31	23	15
-	5SD30/6	5.5	7.5			59	57	53	49	44	37	28	17
-	5SD30/8	7.5	10			79	76	71	65	58	49	37	23
-	5SD30/9	9.2	12.5			88	85	79	74	65	56	42	26
-	5SD30/11	11	15			108	104	97	90	80	68	51	32
